22" Class LCD HDTV

MODEL NUMBER: VA220E Model Features:
  • •  21.6 inch diagonal
  • •  SRSTruSurround XT™
  • •  2 HDMI Ports
  • •  Exceeds version 3.0 ENERGY STAR® Specifications



  • Overview
  • Tech Specs
  • Customer Ratings
  • More Photos
  • Support

Product Overview

ECO HD™ Performance This 22” Class (21.6 inch diagonal) ECO HD™ TV is energy efficient exceeding the current Energy Star® guidelines by at least 15%, saving you money on your utility bills. The High Definition resolution and elegant design make it the perfect HDTV for small spaces.

ECO HD™
ECO HD

ECO HD™ exceeds the current Energy Star Guidelines by 50% below Energy Star 3.0, saving you money on your utility bills while limiting the impact on our planet.

Additional Features Include:

• Two - 3W speakers provide the ultimate home theatre sound experience that will truly set it apart from the competition





Tech Specs

SPECIFICATIONS
Class: 22"
Viewable: 21.6" diagonal
Tuner: 1xRF (F connector for internal NTSC/ATSC/QAM tuner)
Native Panel Resolution: 1366x768
Signal Compatibility: Supports 480i (SDTV), 480P (EDTV), 720P (HDTV), 1080i (HDTV)
Colors: 16.7 Million
Computer Support: 640x480, 800x600, 1024x768, 1366 x 768 via VGA
Dynamic Contrast Ratio: 5,000:1
Brightness: 350 cd/m2 (typical)
Response Time: 5ms
Viewable Angle: 170/155 degrees (horizontal/vertical)
Pixel/Dot Pitch: 0.349mm (H) x 0.349mm (V)
SRS TruSurround HD™: No
SRS TruVolume™: No
SRS TruSurround XT™: Yes



INPUTS (REAR)
HDMI with HDCP 2
RF Connector for Internal Tuner 1
Component YPbPr plus Stereo Audio: 1
S-Video:
Computer RGB: 1
Composite Video:
USB Ports:
Service Ports:



INPUTS (SIDE)
HDMI with HDCP
RF Connector for Internal Tuner
Component YPbPr plus Stereo Audio:
Composite Video: 1
S-Video:
Computer RGB:
USB Ports:
Music (MP3):
Video (MPG):
Photo (JPEG):
Service Ports:



OUTPUTS (REAR)
SPDIF Digital Optical: 1
Stereo Audio:
Headphones: 1



ADDITIONAL FEATURES
Refresh Rate: 60Hz
Smooth Motion: No
LED: No
Picture-in-Picture (PIP): No
Picture-outside-Picture (POP): No
Zero Bright Pixel Defect Guarantee:
V-Chip: Yes
3D Comb Filter: Yes
3:2 or 2:2 Reverse Pull-down: Yes
ATSC with 8VSB & QAM demodulation: Yes
ATSC with MPEG-2 decoding: Yes
NTSC Video decoding via Video: Yes via RF or Composite Video
Progressive Scan Video: Yes, thru Component VGA or HDMI
Color Temperature: 6500K, 5400K and 9300K
Color Fine Tuning: Independent Red, Green and Blue
Speakers: Built-in 3W x 2 Speakers
Panel Lamp Life (typical): 50,000 hours
Voltage Range: 100~240Vac at 50/60 Hz
Power Consumption: 23.7W (average), <1W Standby
Universal Remote: VIZIO Remote Control - VR1



WEIGHT
Gross: 15.44
Net With Stand: 11.9 lbs
Without Stand: 11.1 lbs



DIMENSIONS
With Stand: 20.9" W x 16.1" H x 6.6" D
Without Stand: 20.9" W x 14.3" H x 2.5" D
Packaging Dimensions: 22.68" W x 18.23" H x 5.71"D



CERTIFICATIONS Energy Star 3.0



COMPLIANCES CSA/CSA-US, FCC Class B



WALL MOUNT SPECIFICATIONS
Hole Pattern: 100mm x 100mm
Screw Size: M4
Screw Length: 10mm
Screw Pitch: 0.7mm



VIZIO WARRANTY One Year Parts & Labor, Free lifetime Technical Support.
